Photogrammetry is the process of measuring and reconstructing 3D geometry from overlapping 2D photographs. You take many photos of an object or scene from different positions, and software finds matching points across those images to calculate where the camera was and where each point sits in 3D space. The result is typically a point cloud, a mesh, and a textured model. It works best when your photos overlap heavily, are sharp, and are lit consistently — and it struggles when images are blurry, poorly lit, or shot with too little overlap.

The core idea in plain terms

Every photo is a 2D projection of a 3D scene. If you photograph the same physical point from two or more positions, that point appears at different pixel locations in each image. The software identifies these corresponding points, then solves for two things at once:

• Camera pose — where each camera was and which way it was pointing.
• 3D point position — where the matched point actually sits in space.

This is the same principle your eyes use for depth perception: two slightly different views let you triangulate distance. Photogrammetry scales that up to dozens or hundreds of views.

The typical pipeline

Most photogrammetry tools follow a similar sequence, though the names and automation level differ.

1. Image capture

You photograph the subject from many angles with consistent exposure. Overlap between neighboring shots is what makes matching possible.

2. Feature detection and matching

The software finds distinctive points (corners, edges, textures) in each image and matches them across photos. Flat, textureless surfaces give it little to work with.

3. Camera tracking (sparse reconstruction)

Using the matches, it estimates camera positions and orientations and builds a sparse point cloud — a rough skeleton of the scene.

4. Dense reconstruction

From the sparse result and the original pixels, it computes a dense point cloud covering the surfaces.

5. Meshing and texturing

The dense cloud is converted into a mesh (triangles), and the original photos are projected onto it to produce a textured model.

AliceVision describes itself as a "Photogrammetric Computer Vision framework for 3D Reconstruction and Camera Tracking," and Meshroom is its graphical front end — so the pipeline above maps directly onto what that toolchain does.

What makes a good photo set

The quality of your input determines the quality of your output more than any setting.

Typical outputs

• Sparse point cloud — camera positions plus a rough set of 3D points.
• Dense point cloud — a detailed set of surface points.
• Mesh — a triangulated surface, often cleaned and decimated.
• Textured model — the mesh with photographic texture applied, ready for viewing or export.

Choosing a tool

AliceVision/Meshroom is an open-source photogrammetric computer vision framework with a node-based workflow, suited to users who want control over each pipeline stage and don't mind a learning curve. Other photogrammetry tools range from fully automated consumer apps to professional suites; the right pick depends on how much control you want, whether you need open-source licensing, and how large your datasets are. If you want to understand the pipeline stage by stage, a node-based framework like Meshroom makes each step visible; if you just want a model quickly, a more automated tool will get you there with less setup.

Common failure points

• Blurry or low-overlap images — the most frequent cause of failed or patchy reconstructions.
• Reflective, transparent, or textureless surfaces — matching finds too few reliable features.
• Inconsistent lighting — moving shadows break matches between shots.
• Too few angles — gaps in coverage become holes in the model.
• Scale ambiguity — reconstruction gives relative shape; absolute size needs a known reference measurement in the scene.

If a reconstruction fails, the fix is usually in the photos, not the settings: add more overlap, improve lighting, and remove blurry shots before reprocessing.

Geotechnical engineering is the branch of civil engineering that predicts how soil, rock, and groundwater will behave under a structure or slope, then designs the ground, foundations, or stabilization measures so that behavior stays safe. It applies whenever a project touches the ground: buildings, dams, levees, highways, tunnels, and pipelines. The field matters most where ground conditions are variable, where water is present, or where seismic and geologic hazards are possible — conditions that make simple assumptions unreliable.

Why the Ground, Not Just the Structure, Governs Design

A structure rarely fails because its concrete or steel was too weak. More often the ground moves, settles, or loses strength, and the structure above follows. Geotechnical engineers therefore work from the ground up:

• Soil and rock properties — strength, stiffness, permeability, and how these change with moisture, stress, and time.
• Groundwater — pore water pressure reduces effective stress and is a leading driver of slope instability and settlement.
• Load transfer — how weight from a structure spreads into the ground, and how the ground pushes back.

Because these properties vary from point to point and are never known exactly, geotechnical design is probabilistic and observational: engineers design for a range of conditions and then verify actual behavior during and after construction.

Core Subareas

These overlap in practice. A landslide near a dam, for example, involves slope stability, seepage, and dam safety simultaneously.

How a Project Typically Unfolds

1. Site investigation — borings, test pits, geophysics, and laboratory testing to characterize soil, rock, and groundwater.
2. Analysis and design — stability, settlement, seepage, and seismic models translate investigation data into design decisions.
3. Construction support — observation during excavation and foundation work, with design adjustments as conditions are exposed.
4. Instrumentation and monitoring — sensors track movement, pressure, and settlement over time, confirming performance or triggering action.

The sequence is iterative. New data from any stage can send the project back to an earlier one.

Common Failure Modes and How They Are Mitigated

• Slope failure / landslide — mitigated by regrading, drainage, retaining structures, anchors, or ground improvement.
• Excessive settlement — mitigated by deep foundations, ground improvement, or preloading.
• Liquefaction — mitigated by densification, drainage, or foundation redesign.
• Rockfall — mitigated by scaling, bolting, mesh, barriers, or catchment ditches.
• Seepage and internal erosion — mitigated by filters, cutoffs, and drainage control, especially in dams and levees.

Where This Expertise Is Concentrated

Firms in this field often specialize across dam and levee safety, landslide investigation and stabilization, rockfall and rock slope mitigation, earthquake engineering, and geotechnical instrumentation. Cornforth Consultants, Inc. – Landslide Technology (CCI-LT), for example, describes itself as an employee-owned small business founded in 1983, headquartered near Portland, Oregon, with offices in Boise, Olympia, and Minot, working across the Pacific Northwest, Mountain States, Alaska, and nationally. Its stated project experience includes rock slope mitigation along a 27-mile corridor of Interstate 15 between Helena and Great Falls, Montana.

That profile illustrates a practical point: geotechnical work is regional. Local geology, climate, and seismic setting shape which hazards dominate and which methods are appropriate, so experience in a given terrain is a meaningful selection criterion when choosing a firm.

What to Take Away

Geotechnical engineering exists because the ground is the least predictable part of most civil projects. It defines the problem through investigation, quantifies risk through analysis, and manages it through design and monitoring. If you are scoping a project, the questions worth asking early are: what are the ground and groundwater conditions, what hazards apply, and how will performance be verified after construction?

A landslide is the downslope movement of soil, rock, or debris under gravity, and stabilizing one means reducing the forces that drive that movement or increasing the forces that resist it. Geotechnical firms that specialize in this work—such as Cornforth Consultants, Inc. – Landslide Technology (CCI-LT), an employee-owned firm founded in 1983 that handles landslide investigation and stabilization, rockfall and rock slope mitigation, dam and levee safety, and geotechnical instrumentation—typically approach it in two phases: first investigate and monitor, then design and build stabilization measures. This explanation covers how landslides differ from related hazards, what triggers them, how engineers investigate them, and which stabilization methods are commonly used.

Landslide vs. related ground-failure hazards

These terms are often used interchangeably, but they describe different mechanisms and call for different responses:

The distinction matters because mitigation differs. Rockfall mitigation focuses on catching, containing, or preventing detachment from rock slopes, while landslide stabilization targets the mass movement itself. CCI-LT lists landslide investigation and stabilization and rockfall and rock slope mitigation as separate areas of expertise, reflecting that these are treated as distinct engineering problems.

What triggers a landslide

Landslides result from a combination of contributing factors and a trigger that pushes a slope past its limit.

Contributing factors (make a slope vulnerable):

• Slope steepness and geometry
• Soil or rock properties, including weak layers or existing failure surfaces
• Groundwater conditions and pore-water pressure
• Prior movement or weathering

Triggers (set movement in motion):

• Heavy or prolonged rainfall
• Earthquakes and seismic shaking
• Excavation, loading, or changes to drainage at the top or toe of a slope

Because earthquake engineering and hydrogeology both appear among CCI-LT's service areas, seismic shaking and groundwater are treated as core parts of landslide analysis rather than afterthoughts.

How engineers investigate a landslide

Investigation establishes what is moving, how much, and why before any stabilization is designed. Typical elements include:

1. Field mapping and reconnaissance — identifying the extent of movement, scarps, cracks, and seepage zones.
2. Subsurface exploration — determining the depth and shape of the failure surface and the soil or rock layers involved.
3. Instrumentation and monitoring — tracking whether movement is active, slowing, or accelerating over time. Geotechnical instrumentation is a named CCI-LT service, which reflects how central monitoring is to both diagnosis and confirming that a fix is working.

The output of this phase is the basis for choosing stabilization methods: you cannot size a drainage system or an anchor without knowing the failure geometry and the groundwater regime.

Common stabilization methods

Stabilization generally works by one of two levers—removing the driving force or adding resistance—and projects often combine several methods.

• Drainage — lowering groundwater and pore-water pressure so the slope has more effective strength. Often the most cost-effective first measure.
• Regrading — removing material from the top of the slide (reducing driving force) and/or adding a buttress at the toe (adding resistance).
• Retaining structures — walls or similar structures that hold back the moving mass.
• Ground anchors — anchoring the unstable mass to more stable ground beneath or behind it.
• Rock slope mitigation — for rock-dominated slopes, measures such as scaling, bolting, or protection systems, handled as a distinct discipline from soil landslides.

The right combination depends on the failure depth, the consequences of failure, and site constraints—which is why investigation precedes design.

When to bring in a geotechnical engineer

Bring in a specialist when you see evidence of active or historical movement—tension cracks, tilted trees or poles, offset roads or walls, or new seepage—especially if people or infrastructure are downslope. Because landslides can affect dams, levees, highways, and other civil infrastructure, the stakes often extend beyond the immediate slope.

Before contacting a firm, gather what you can:

• Location and approximate extent of the movement
• When it started and whether it is still moving
• Visible signs (cracks, scarps, seepage, damaged structures)
• Any history of prior slides at the site
• What is at risk downslope

That information lets an engineer scope the investigation efficiently. Firms like CCI-LT, headquartered near Portland, Oregon, with offices in Boise, Olympia, and Minot, work across the Pacific Northwest, Mountain States, Alaska, and nationally—so regional experience with local geology is a reasonable thing to ask about when selecting one.

Rockfall mitigation is the set of engineering measures used to reduce the risk that falling or bouncing rock poses to people, vehicles, and infrastructure below a slope. It differs from general rock slope stabilization in that mitigation can either prevent detachment (source control) or manage the rock after it falls (containment or deflection). The right combination depends on slope geometry, rock size and energy, the value and exposure of what sits below, and access constraints. Firms such as Cornforth Consultants – Landslide Technology (CCI-LT) describe rockfall and rock slope mitigation as a core geotechnical service, alongside landslide investigation and stabilization, dam and levee safety, and earthquake engineering — a useful reminder that rockfall is usually one hazard within a larger geologic picture.

Rockfall mitigation vs. rock slope stabilization vs. landslide repair

These terms overlap in practice but describe different problems:

• Rockfall mitigation targets rock that detaches from a steep face and travels downslope. The hazard is kinetic energy at the point of impact.
• Rock slope stabilization targets the stability of the rock mass itself — the goal is to keep blocks from moving in the first place.
• Landslide repair deals with soil or rock masses that move as a coherent body, often on a deeper failure surface, rather than individual falling blocks.

A single site can require all three. For example, a highway cut may have a deep-seated landslide in soil beneath a rock face that also sheds boulders — the fix has to address both.

Common rockfall mitigation methods

Methods fall into two broad families: those that stop rock at the source, and those that control rock once it is moving.

Source control (prevent detachment)

• Scaling and trimming — manually or mechanically removing loose blocks and overhangs. Often a first-pass measure, but it is not a permanent fix because new blocks loosen over time.
• Rock bolting and anchoring — installing tensioned bolts or anchors to pin potentially unstable blocks to the stable mass behind them.
• Dowel and cable systems — used where individual blocks or wedges need to be tied back.
• Shotcrete and mesh facing — covering a face to hold small fragments and reduce weathering-driven loosening.

Containment and deflection (manage falling rock)

• Rockfall barriers — engineered fence systems designed to absorb a specified impact energy. Their capacity is rated, so they must be matched to the site's energy demand.
• Drapery mesh — a continuous mesh blanket over the face that guides falling rock down to a controlled collection point rather than letting it bounce freely.
• Catchment ditches and benches — excavated areas at the toe that intercept rock. Their effectiveness depends on width, depth, and the trajectory of the falling material.
• Attenuators and embankments — engineered barriers that absorb energy before rock reaches the asset.
• Rockfall warning and monitoring systems — detection that triggers alerts or closures rather than physically stopping rock.

How site conditions drive method selection

There is no default method. Selection is an energy-and-exposure problem. The key variables:

A high, steep face shedding large blocks onto a busy interstate calls for a different solution than a low cut above a rarely used access road. CCI-LT's work on rock slope mitigation along a 27-mile corridor of Interstate 15 between Helena and Great Falls, Montana, illustrates the corridor scale at which these decisions are often made — long stretches of varying geology and exposure rather than a single isolated slope.

Typical steps in assessing a rockfall hazard and designing mitigation

1. Desk study and site reconnaissance — review geology, history of rockfall events, and asset exposure.
2. Hazard and risk assessment — identify source areas, estimate block sizes, and model or observe trajectories to estimate energy at the asset.
3. Develop mitigation alternatives — combine source control and containment options, each with a capacity and cost.
4. Design and specify — size barriers, mesh, bolts, or ditches to the calculated demand, with appropriate factors of safety.
5. Construct and commission — install, then verify that systems meet design intent.
6. Inspect and maintain — barriers fill with debris, mesh corrodes, bolts lose tension, and ditches clog. Maintenance is part of the design life, not an afterthought.

Warning signs a slope needs investigation or maintenance

• Fresh rock fragments or dust on the road, ditch, or bench that were not there before
• New cracks, opened joints, or displaced blocks on the face
• Existing mesh that is torn, sagging, or full of accumulated rock
• Barrier posts that are bent, foundations that have moved, or debris at the base of the barrier
• Ditches or catchment areas that are full and no longer have capacity
• Changes above the slope — construction, vegetation removal, or drainage alterations — that could destabilize blocks

Any of these warrants a geotechnical review before the next significant storm or freeze-thaw cycle.

Choosing among methods: a conditional guide

• If the face is accessible and blocks are few and large → bolting or anchoring may be the most direct fix.
• If the face is high and inaccessible → drapery mesh or barriers may be more practical than source control.
• If the asset is close to the toe and space is limited → barriers or attenuators may fit where a wide ditch cannot.
• If rock is small and the slope is moderate → a properly sized catchment ditch may be sufficient and low-maintenance.
• If the consequence of a single rock reaching the asset is severe → combine source control with containment and monitoring rather than relying on one measure.

Because rockfall mitigation is a geotechnical engineering problem, the design should be developed by qualified engineers and geologists using site-specific data. The general methods above describe the options; the selection and sizing require site investigation and analysis.
