What is Axometrics?
Axometrics is a manufacturer of Mueller matrix polarization metrology instruments: systems that measure the full polarization properties of materials and optical components. Its tools are aimed at R&D labs, quality control groups, and production lines where polarization behavior matters, such as LCD panels, polarizers, retarders, optical films, and anisotropic thin films.
Its product line centers on two measurement families:
- AxoScan — a lab measurement system for testing polarization-critical components, positioned around speed, repeatability, accuracy, and flexibility.
- AxoStep — described as a Mueller matrix imaging microscope, for measuring polarization properties at a microscopic scale.
Supporting hardware includes light sources, calibration standards, polarization standards, wavelength verification, and thin-film test standards, plus standard and application-specific software that converts measured Mueller matrices into parameters for particular tasks.
Who it is for: engineers and scientists who need to understand all polarization properties of a sample, not just one or two. Typical uses include birefringence mapping, polarizer and retarder testing, LCD cell gap testing, circular polarizer analysis, LCOS panel testing, and thin-film measurement.
Practical next step: if you are choosing between AxoScan and AxoStep, decide first whether you need bulk or spot measurement of a component versus spatial imaging of polarization across a microscopic area. If you need the latter, AxoStep is the relevant starting point; for general lab or production testing of polarization-critical parts, start with AxoScan. You can review the product pages at Axometrics.
How does Mueller matrix polarimetry measure LCD cell gap and other display panel parameters?
Mueller matrix polarimetry measures an LCD panel by sending polarized light through the cell and recording how the sample transforms that light. A Mueller matrix describes all polarization-changing behavior of a sample, so it captures both retardance and diattenuation in one measurement rather than requiring separate setups. For an LCD cell, the liquid crystal layer acts as a voltage-dependent retarder; its retardance depends on the cell gap (thickness), the material's birefringence, and the applied voltage. By fitting the measured data to a model of that retarder, the system extracts cell gap and related parameters.
Axometrics builds its systems around this principle. According to the site, AxoScan and AxoStep measure the full Mueller matrix of a sample, and the company supplies application-specific software that converts measured matrices into key parameters for tasks such as LCD cell gap testing, polarizer and retarder testing, birefringence mapping, and thin-film measurement.
H3 What the measurement actually yields
- Cell gap and twist/tilt behavior of the liquid crystal layer
- Retardance and its variation across a panel
- Polarizer and retarder film properties (axis orientation, efficiency)
- Birefringence maps and anisotropic thin-film parameters
- Circular polarizer behavior and analysis
H3 Why full Mueller matrix matters for displays A display stack combines several polarization elements: polarizers, retarders, the LC layer, and sometimes compensation films. Their effects overlap, and a simpler single-parameter measurement can be ambiguous. A full Mueller matrix captures the combined optical behavior, and software then separates the contributions. This is why the approach suits both R&D and production environments, where speed, repeatability, and accuracy all matter.
H3 Practical decision criterion If your goal is a single known quantity on a stable process, a simpler retardance measurement may be enough. If you need to understand a stack of polarization elements, map properties across a panel, or diagnose how the LC layer behaves under different voltages, a full Mueller matrix system is the better fit. For imaging across a microscopic area rather than a single point, an imaging Mueller matrix microscope addresses that need.
Next step: define which parameters you must report (cell gap, retardance, film axis, uniformity) and at what scale (spot, line, or full-panel map). That determines whether a point system or an imaging system such as AxoStep is appropriate. You can review the product lines at Axometrics.
What is the difference between AxoScan and AxoStep for polarization measurement?
AxoScan and AxoStep both measure the full Mueller matrix; the practical difference is scale and imaging. AxoScan is presented as a high-speed, high-accuracy point-measurement system for polarization-critical components, while AxoStep is described as the industry's first Mueller Matrix imaging microscope, aimed at mapping polarization properties on a microscopic scale. In short: choose AxoScan when you need the fastest, most repeatable single-point or spot measurements; choose AxoStep when you need spatial maps of how polarization varies across a sample.
How to think about the trade-off
| Criterion | AxoScan | AxoStep |
|---|---|---|
| Measurement type | Point/spot Mueller matrix measurement | Mueller matrix imaging at microscopic scale |
| Best for | Fast, repeatable testing of polarizers, retarders, films, LCD panels | Mapping birefringence, defects, or uniformity across small areas |
| Output emphasis | Precise polarization parameters for a location | Spatial distribution of polarization properties |
| Typical setting | R&D labs, QC, production | Microscopic polarization analysis within R&D or failure analysis |
A concrete scenario
If you are qualifying a batch of polarizer film and need a fast pass/fail number per sheet, AxoScan's speed and repeatability matter most. If instead you are investigating why one corner of an LCOS panel behaves differently from the rest, AxoStep's imaging shows you where the polarization state changes, not just what it is at one point. Many labs would use both: AxoStep to locate and understand a non-uniformity, AxoScan to verify it quickly across many samples.
Next step
List your measurements as either "one number per sample" or "a map per sample." If maps dominate, AxoStep is the natural fit; if throughput and repeatability dominate, AxoScan is. For the exact configurations, software options, and calibration standards, review the product pages at Axometrics.
Which Axometrics system should I choose for inline production versus R&D lab testing?
For inline production, choose the Large & Inline Measurement configurations (large/inline polarizer and retarder film, large/inline LCD panel, or large/inline ellipsometry). For R&D lab work, choose AxoScan or AxoStep. AxoStep is the imaging option: it is described as a Mueller Matrix imaging microscope for measuring polarization properties on a microscopic scale.
H3 How to decide
- If you are measuring large sheets, panels or films on a line, the inline systems are built for that format and setting.
- If you need the fastest, most flexible measurements of polarization-critical components in a lab, AxoScan is the general-purpose choice.
- If you need spatial maps at microscopic resolution — for example, locating defects or uniformity across a small area — AxoStep is the better fit.
H3 Practical example A display maker checking retarder film on a production line would look at the Large & Inline options. A lab developing a new optical film, where you also want to see how properties vary point to point, would pair AxoScan for bulk measurements with AxoStep when microscopic imaging matters.
H3 Decision criterion Start from the sample: size and format (large sheet versus small coupon), whether it is moving on a line or stationary in a lab, and whether you need a single measurement or an image map. Those three answers usually settle the choice.
Next step: list your applications (LCD panel testing, polarizers and retarders, optical films, birefringence, LCOS panels, anisotropic thin films, circular polarizers) and match them against the application-specific software Axometrics provides, since the software converts measured Mueller matrices into the parameters your process actually uses.
How do I calibrate an Axometrics polarimeter using polarization standards?
Calibrating an Axometrics system means measuring known reference standards and letting the instrument's software compare measured Mueller matrices against the expected values, then applying the correction. Axometrics supplies the standards themselves, so the practical path is: confirm which standards your instrument and software expect, measure them under the same conditions as your samples, and run the calibration routine in the analysis software. The page lists Polarization Standards, Wavelength Verification, and Thin-Film Test Standards under Calibration Standards, along with Standard Software and Application-Specific software — the calibration workflow lives in that software rather than in a separate utility.
A practical calibration sequence
- Warm up and stabilize. Let the light source and detector reach steady output; polarization measurements drift with temperature and lamp aging. If you use an external source (the page lists MALT-1, TVS-2, and LED-1), give it time to settle first.
- Set the configuration you will actually measure with. Wavelength, aperture, and any imaging optics change the polarization state reaching the sample. Calibrate in the same setup, not a convenient one.
- Measure the reference standards. Start with the polarization standards, then wavelength verification, then thin-film standards if your work involves film thickness or anisotropic films. Each targets a different error source.
- Let the software compute and apply corrections. The application-specific software converts measured matrices into the parameters you care about; the calibration constants it derives should be saved as a named configuration so you can reload them.
- Verify with an independent standard. Re-measure a standard you did not use for fitting. If it agrees, the calibration is sound; if not, you have likely over-fitted to one reference.
- Re-check on a schedule. Repeat after source changes, after any optical realignment, and at intervals set by your own stability data — not by a fixed habit.
Choosing the right standard for the job
| Goal | Standard type | What it catches |
|---|---|---|
| Overall matrix accuracy | Polarization standards | Element misalignment, retardance and diattenuation errors |
| Wavelength scale | Wavelength verification | Monochromator or filter drift |
| Film and coating work | Thin-film test standards | Thickness and anisotropic film model errors |
For a concrete case: a lab measuring retarder film on a roll would calibrate with polarization standards at the production wavelength, verify with a wavelength standard, and keep a thin-film standard on hand for the film-thickness channel. A lab doing LCOS panel work would weight the matrix accuracy step more heavily, since cell gap and twist depend on the full matrix rather than a single retardance value.
If your instrument is an AxoScan or AxoStep system, the fastest next step is to ask Axometrics which standards and software module match your exact configuration — the calibration procedure is tied to the specific system and application software, and the page's resources section (tutorials, polarization glossary) is where the underlying concepts are explained. For background on Mueller matrix polarimetry generally, Axometrics is the vendor source, and independent optics references are worth consulting for the theory behind each standard.
What software does Axometrics offer to convert Mueller matrices into application-specific parameters?
Axometrics frames its software as the step that turns a measured Mueller matrix into the numbers an application actually cares about. The site describes “application-specific software” developed in response to customer requirements, plus a “Standard Software” category. The application list on the page begins with basic parameters and thin-film parameters, and the broader applications include LCD panel testing, polarizers and retarders, optical films, birefringence testing, LCOS panels, anisotropic thin films, and circular polarizer testing and analysis.
In practice, that means the hardware captures the full Mueller matrix, and the software translates it into decision-ready outputs such as:
- Basic polarization parameters
- Thin-film parameters
- LCD cell gap and panel-related measurements
- Polarizer, retarder, and optical film characteristics
- Birefringence maps and anisotropic thin-film data
- Circular polarizer analysis
The useful distinction is between standard software and application-specific modules. Standard software is the general-purpose layer; application-specific software is what converts matrices into the key parameters for a particular test. If you are comparing options, ask which application module matches your sample type and which parameters it reports, rather than assuming a general polarimetry package covers your use case. For related background, Axometrics publishes tutorials and a polarization glossary that can help you specify the right parameter set before choosing software.
