onlinecables.com

OnlineCables (Applied Interconnect Inc.) holds an ISO-9001:2015 certified quality program and states that its assemblies are RoHS compliant and built to J-STD-001, with IPC/WHMA-A-620 as the workmanship specification for commercial products. It also states registration for US/Canada Joint Certification for Military Critical Technical Data and ITAR requirements. These claims are relevant if you need documented quality management and military/aerospace program experience; they are not a substitute for confirming current certificates and flow-down requirements on your specific order.

Certifications and standards stated on the site

Military and aerospace program experience

The site lists participation in programs including AMRAAM, F-35 (Joint Strike Fighter), APG-79 Radar (F-18), APQ-181 Radar (B2), HARM, Global Hawk, GPS flight hardware, Airborne Laser (ABL), M1A1 Tank, M2 Bradley, and the Apache Helicopter. It also states Applied Interconnect is a prime military contractor for the US Air Force, NASA, US Navy, US Army, and Government of Canada.

Use this as evidence of relevant experience when you are screening suppliers. For a specific procurement, ask for the quality clauses, inspection data, and certificates that apply to your contract rather than relying on program names alone.

Practical checks before you order

• Request the current ISO-9001:2015 certificate and confirm the scope covers RF cable assemblies.
• Confirm the J-STD-001 revision and IPC/WHMA-A-620 class your program requires, and whether the supplier will build and inspect to them.
• Ask for a RoHS declaration or test documentation for the exact materials and connectors in your assembly.
• If your data is military-critical or export-controlled, confirm ITAR/JCP registration and how drawings will be handled before sending files.
• Note the stated $150 minimum order size and standard delivery of typically 2–4 working days ARO; confirm both for your quantity and schedule.

Where these standards fit in the ordering process

OnlineCables offers online design and ordering of custom RF coaxial cable assemblies, including semi-rigid, flexible, conformable coax, VNA cables, Heliax, circular military, and custom military harnesses, with connectors such as SMA, SSMA, BNC, SMP, TNC, N, MMCX, MCX, SMB, SSMB, F, UHF, SMC, and SSMC. The site also lists RF delay lines, time delay and phase matching, and RF testing of cable assemblies.

Compliance details matter most at two points: when you specify the assembly (materials, plating, soldering standard, RoHS) and when you accept the product (inspection and test data). If a requirement is not visible in the online tool, the site directs customers to call 408 749-9900 for specials, so use that channel to confirm certification and flow-down before release.

OnlineCables (Applied Interconnect Inc.) lets you design and order custom RF coaxial cable assemblies directly on its website, with a stated $150 minimum order and standard delivery typically 2–4 working days ARO. You can configure assemblies online using your own part numbers and logos and save the drawings; for anything not listed on the site, the company directs you to call 408-749-9900 to discuss specials. These details suit buyers who need small-to-moderate quantities of custom or semi-custom RF assemblies and want a fast standard turnaround, but who should confirm schedule and pricing directly before committing to a production run.

What You Can Order

The site covers a broad catalog from DC to 40 GHz, including:

• RF coaxial cable assemblies — semi-rigid, flexible coax, conformable coax, Heliax, VNA cables, circular and military types
• Connector options — SMA, SSMA, BNC, SMP, TNC, N, MMCX, MCX, SMB, SSMB, F, UHF, SMC, SSMC
• Related assemblies — RF delay lines, time delay and phase-matched cable assemblies, military harnesses (including M38999), fiber optic cable assemblies, and power cords
• Custom work — assemblies using Silicone, PTFE, ETFE, FEP, or Estane; connectors in stainless steel or other materials; waveguide adapters, filters, and power distribution assemblies

The site also states that all cable assemblies are RoHS compliant.

Ordering Details at a Glance

How the Online Design and Order Flow Works

1. Start from the cable assembly section of the site (RF Cables: semi-rigid, flexible coax, conformable coax, VNA cables, Heliax, circular, military, custom harnesses).
2. Configure the assembly — the site states you can design cable assemblies "in seconds" using your own part numbers and logos.
3. Save the drawing — configured drawings can be saved, which is useful for repeat orders or internal approval.
4. Place the order, keeping the $150 minimum in mind.
5. Expect shipment typically 2–4 working days ARO for standard items.

Verification: Before ordering, confirm the connector/cable combination and any phase-matching or delay-line requirements match your drawing, since custom configurations are built to your specification.

When to Call Instead of Ordering Online

Call 408-749-9900 if:

• The assembly or connector you need isn't listed on the site ("If you cannot find it on the web we do specials")
• You need lead-free assemblies
• You need custom connectors in stainless steel or other materials, waveguide adapters, filters, or power distribution assemblies
• You want to confirm pricing, quantity breaks, or schedule for a larger order — the site gives the minimum and typical lead time but no published price list

Quality and Compliance Context

The company states it is ISO-9001:2015 certified (cage # 0X997) and certified to J-STD-001, with commercial workmanship to IPC/WHMA-A-620. It also states registration under US/Canada Joint Certification for Military Critical Technical Data and ITAR requirements, and lists prime military contractor work (e.g., AMRAAM, F-35, APG-79, HARM, Global Hawk, GPS flight hardware). These claims are relevant if your project requires documented quality systems or military-grade traceability — ask for certificates when quoting.

Practical Takeaways

• Budget for at least $150 per order; small prototype quantities below that threshold aren't orderable as stated.
• Plan around 2–4 working days ARO for standard assemblies, and add time for specials or custom connectors arranged by phone.
• Use the online configurator and saved drawings for repeatability, but route non-catalog or lead-free requirements through the phone line.
• Confirm price, quantity, and schedule directly — the site publishes minimums and lead times but no pricing.

OnlineCables (Applied Interconnect) lets you configure a custom RF coaxial cable assembly on its website, enter your own part number and logo, and save the drawing for later — then order online. The site states assemblies can be designed "in seconds." This suits buyers who need a documented, buildable cable spec (connector types, cable type, assembly style) rather than a stock catalog part. Note the stated $150 minimum order, standard delivery of 2–4 working days ARO, and that specials not configurable on the site require a phone call to 408-749-9900.

What you can configure

The site lists these product families and options:

Frequency range is stated as DC to 40 GHz.

Step-by-step: designing and ordering

1. Pick the assembly type. Start from the cable family that matches your application (e.g., semi-rigid for fixed runs, flexible coax for routing, phase-matched for delay-sensitive systems).
2. Select connectors at each end. Choose from the connector list above; the tool builds the assembly from your selections.
3. Enter your part number and logo. The site explicitly supports using your own part numbers and logos on the drawing — useful if the assembly feeds into your own configuration management.
4. Save the drawing. Saved drawings let you reuse the same configuration for repeat orders or internal review.
5. Place the order online. Confirm the build meets the $150 minimum; standard lead time is quoted at 2–4 working days ARO.
6. Escalate anything non-standard. If your requirement isn't configurable (custom materials, waveguide adapters, filters, lead-free builds), call 408-749-9900 rather than forcing a near-match through the tool.

Verification: before ordering, check the saved drawing against your requirements — connector gender and type, cable type, length, and part number. The drawing is the build document, so errors there carry into the delivered assembly.

Quality and compliance context

The site states ISO-9001:2015 certification (cage # 0X997), J-STD-001 certification, RoHS compliance, and IPC/WHMA-A-620 as the workmanship standard for commercial product. It also cites participation in military programs (AMRAAM, F-35, APG-79, APQ-181, HARM, Global Hawk, GPS flight hardware, ABL, M1A1, M2 Bradley, Apache) and ITAR/US-Canada Joint Certification registration. These claims matter if your assembly needs to fit an existing qualified supplier list — verify current certification status directly if that's a procurement requirement.

Common sticking points

• Minimum order: small prototype quantities below $150 aren't orderable as stated.
• Lead time is ARO: the 2–4 working days clock starts on order receipt, not on quote.
• Specials need a call: the online tool covers standard configurations; custom materials and non-catalog assemblies are phone-only.
• Part number discipline: using your own part numbers is convenient but means your internal system must track the revision of the saved drawing.

OnlineCables (operated by Applied Interconnect) offers custom RF coaxial cable assemblies built around a broad connector and cable selection. According to the site, connector options include SMA, SSMA, BNC, SMP, TNC, N, MMCX, MCX, SMB, SSMB, F, UHF, SMC, and SSMC, while cable categories cover semi-rigid, flexible coax, conformable coax, VNA cables, Heliax, circular, and military assemblies. The catalog spans DC to 40 GHz, and the company also builds custom connectors and specialty assemblies beyond the standard list. If your design uses one of these interfaces and a coax style in this range, you can likely configure it as a custom assembly; anything outside the listed options requires a special request by phone.

Connector Options

The site lists the following RF connector types for custom cable assemblies:

Custom connectors are also available, including versions made from stainless steel or other materials. That matters if your assembly needs a non-standard body material or a connector that isn't in the standard list.

Cable and Assembly Categories

OnlineCables organizes its RF cable offerings into these categories:

• Semi-rigid coax — formed coaxial cable for fixed, precision runs
• Flexible coax — bendable cable for routing where semi-rigid won't work
• Conformable coax — hand-formable cable that holds its shape
• VNA cables — assemblies intended for vector network analyzer test setups
• Heliax — corrugated coaxial cable, typically for lower-loss runs
• Circular and military assemblies — including MIL-STD-38999 harnesses
• Custom military harnesses — built to military program requirements

Beyond cables, the company lists related custom assemblies: waveguide adapters, filters, and power distribution assemblies. It also produces RF delay lines and phase-matched assemblies, which are relevant if timing or phase consistency across a run is part of your requirement.

Jacket and Material Choices

Custom cable assemblies can be built with Silicone, PTFE, ETFE, FEP, and Estane jackets. These choices affect flexibility, temperature behavior, and abrasion resistance, so the right pick depends on where the cable will be installed. The site does not publish a per-material specification table, so confirm the exact jacket for your environment when you order.

What This Means for Your Design

Use the list above as a first filter:

1. Check the connector. If your interface is SMA, BNC, N, TNC, SMP, MMCX, or another listed type, it fits the standard custom-assembly flow.
2. Check the cable style. Semi-rigid, flexible, conformable, VNA, Heliax, and military categories are all offered.
3. Check the frequency. The published range is DC to 40 GHz; confirm your operating frequency against the specific cable and connector combination.
4. Check the extras. Delay lines, phase matching, custom connector materials, waveguide adapters, filters, and power distribution assemblies are available as specials.

If your part isn't on the site, the company explicitly invites special requests by phone at 408-749-9900. Assemblies are RoHS compliant, and the quality program is ISO-9001:2015 certified with J-STD-001 certification; commercial workmanship follows IPC/WHMA-A-620.

Practical Notes Before Ordering

• Minimum order: $150.
• Standard delivery: typically 2–4 working days ARO, though custom or special items may differ.
• Design online: the site lets you configure assemblies in seconds using your part numbers and logos and save the drawings.
• Lead-free options: available on request by phone.

The connector and cable lists above come directly from the site's published capabilities, but the site does not detail every cable's electrical specs (loss, impedance tolerance, temperature rating). For a design where those numbers are critical, request the datasheet for the specific cable-connector pairing before committing to an order.

OnlineCables.com is the online storefront of Applied Interconnect Inc., a manufacturer of custom RF coaxial cable assemblies and related interconnect products. It is aimed at engineers and buyers who need made-to-order RF cables rather than off-the-shelf parts: the site lets you design a cable assembly online, save the drawing, and order it. It is a fit if you need custom RF assemblies in small-to-medium quantities and can work within the stated terms (a $150 minimum order and standard delivery of typically 2–4 working days ARO). It is not a general electronics retailer, and the site does not publish prices, so expect to confirm cost and lead time directly.

What you can order

The product range covers RF and related assemblies from DC to 40 GHz:

• RF coaxial cable assemblies — semi-rigid, flexible coax, conformable coax, VNA cables, and Heliax
• Circular and military cables — including MIL-STD-38999 harnesses and custom military harnesses
• RF delay lines and time delay lines, plus phase matching of cable assemblies
• RF testing of cable assemblies
• Other custom assemblies — waveguide adapters, filters, and power distribution assemblies
• Fiber optic cable assemblies and power cords

Connector options listed include SMA, SSMA, BNC, SMP, TNC, N, MMCX, MCX, SMB, SSMB, F, UHF, SMC, and SSMC. Custom connectors can be made in stainless steel or other materials, and cable jackets can use Silicone, PTFE, ETFE, FEP, or Estane.

How the online design and ordering works

The site's core feature is designing a cable assembly in seconds using your own part numbers and logos, with the ability to save the drawings. The page does not document the exact menu flow, so the practical steps are:

1. Go to the site and start a custom RF coaxial cable assembly design.
2. Enter your part number and logo details and select cable and connector options.
3. Save the drawing for review or reuse.
4. Place the order, or call 408-749-9900 for anything not configurable on the web — the company states it handles specials.

Expected result: a saved assembly drawing you can order against. Things to confirm before ordering: the $150 minimum order size, the 2–4 working day ARO standard delivery estimate, and pricing, none of which are published on the page.

Quality and compliance credentials

If your project requires documented quality systems, these are the claims made on the site:

These are the company's own statements; verify current certifications and contract eligibility directly if they are a deciding factor.

When it fits and when to look elsewhere

Choose OnlineCables.com if you need custom RF coaxial assemblies, delay lines, phase-matched cables, or military-style harnesses; you want to define part numbers and logos and save drawings online; and your order can meet the $150 minimum with a few days' lead time.

Look elsewhere if you need published online pricing and checkout, need a single cable below the minimum order, or need a standard catalog part shipped same day — the page describes custom and special-order work, not stocked retail sales.
